For industrial applications up to 30.000 mPas with VISCOPOWER

with new progressive cavity pump VISCOPOWER F 570

Branch: Industrie

Pre-assembled progressive cavity pump kit with progressive cavity pump VISCOPOWER F 570 and planetary gear for industrial applications to pump thin to medium viscous media up to 30.000 mPas out of 200-l drums and IBCs. The positive displacement pump works smoothly at a constant pressure and ensures a gentle, pulsation-free pumping. Comprising progressive cavity pump VISCOPOWER F 570 in 1000 or 1200 mm, Commutator motor F 457, chemical and food hose, discharge spout, ressure connector adaptor and hinged clamp with seal and compression gland.

Technical data:

  • Flow rate: max. 30 l/min
  • Delivery head: max. 60 mwc
  • Viscosity: min. 1 mPas - max. 30000 mPas
  • Outer tube diameter: max. 53 mm
  • Immersion length: 1000, 1200
  • Materials outer tube: Stainless steel
  • Media / Fluids: Viscous media
  • Container: 1000 l IBC, 200 l drums

Product attributes

  • Positive displacement pump
  • Ideally suited to a wide range of low and medium viscosity industrial applications
  • Perfect for viscous, free-flowing media that is sensitive to shearing
  • Intuitive and quick to dismantle and clean
  • Smooth pumping and with very little turbulences
  • Low pulsation in relation to the flow
  • Pump / shaft / worm can be dismantled

Benefits

  • Wide range of viscosity can be covered
  • Optimal for viscous self-flowing media
  • Also suitable for shear-sensitive media
  • Transfer at constant pressure
  • Can be adjusted individually on the media's characteristics
  • Pump can be dismantled
  • Efficient use of medium
  • High efficiency
